Xantrex
Xantrex Freedom Ex4000 4000w Marine Inverter Charger 48vdc In 120vac Out
Xantrex Freedom Ex4000 4000w Marine Inverter Charger 48vdc In 120vac Out
Couldn't load pickup availability
Xantrex Freedom EX 4000 Inverter/Charger with 48VDC-to-12VDC Converter
Model: 820-4080-41- Stack up to 3 units in parallel; up to 2 units in series
- 48VDC to 12VDC converter output
- Highly configurable charger specifically designed for lithium ion batteries
- Built-in 50A Transfer Relay
- Extended Surge Rating to 2X continuous power for 5 seconds
- True Sine Wave AC Power
- Ignition Control Feature to turn inverter on/off via a 12VDC signal
The new FREEDOM EX 4000 is a truly unique, true sine wave power solution packing a powerful 48VDC, 4000W (8000W [5s]) inverter, 80A 48VDC battery charger, 50A transfer relay and a 48VDC to 12VDC, 45A converter inside one box. Designed for mobile applications that utilize 48VDC battery systems, the FREEDOM EX 4000 is designed to work as a standalone AC and DC power solution or supplement an existing generator to create a hybrid system. The FREEDOM EX 4000 features the most widely used communication protocols — RV-C (RV), enabling it to be used in virtually any application that requires integration with 3rd party MFPs and software.
Specifications| ELECTRICAL SPECS - INVERTER | |
| AC Output Operating Voltage Options | 105 - 130VAC |
| Continuous Output Power | Continuous Power 4000 W @40 C True sine wave (TSW) at 120Vac |
| Continuous AC Output Current | 33A |
| Surge Power | 8000W(5 sec) |
| Frequency | 60Hz |
| ELECTRICAL SPECS - BATTERY CHARGER | |
| Nominal DC Output Voltage | 48VDC |
| Charger Voltage Range | 40 - 64VDC |
| Maximum DC Output Current (user configurable down to 5 A) | 80A |
| Supported Battery Types | Flooded, Gel, AGM, Lithium Ion, Custom |
| ELECTRICAL SPECS - PASS-THROUGH | |
| AC Input Voltage: | |
| Single-phase (L1 - N and L2 - N) | 80 - 138Vac |
| Split-phase* (L1 - L2) | 160 - 276Vac |
| Frequency (input/output) | 60Hz |
| Continuous AC current (input/output) | 40A |
| ELECTRICAL SPECS - 12 VDC POWER SUPPLY | |
| Nominal DC Output Voltage (fully regulated) | 13.5VDC |
| Maximum DC Output Current | 45ADC continuous (at 77 F (25 C) ambient) |
| Typical Application* Powering | 12 VDC Loads |
| ELECTRICAL SPECS - COMMUNICATIONS SUPPORTED | |
| Recreational Vehicles (RV) | RV-C Protocol |
| Trucking Vehicles (future offering) | J-1939 Protocol |
| Marine Vessels (future offering) | NMEA-2000 Protocol |
| GENERAL SPECS | |
| Operating Temperature Range | 14 to 140 F (-10 to 60 C), with output derated above 104 F (40°C) |
| Storage Temperature Range | -40 to 158 F (-40 to 70 C) |
| Operating Humidity Range | 5 to 95% RH, non-condensing |
| Transfer Relay AC Current Rating | 50A (40A continuous) |
| L x W x H | 17.1in (434mm) x 14in (354mm) x 8.1in (205mm) |
| Net Weight | 79.4lbs (36.0kg) |
What's in the Box:
- Freedom EX 4000
- Installation guide
- pair of ½"" bushings
- pair of ¾"" bushings
- one network terminator
