Mastervolt Dc Master 24/12-6a 24vdc To 13.6 Vdc - 6a

Mastervolt Dc Master 24/12-6a 24vdc To 13.6 Vdc - 6a

Regular price $88.20
Regular price Sale price $88.20
Sale Sold out

Mastervolt DC master 24/12-6A DC-DC Converter, Non-Isolated

Model: 81400200
  • Recreational and semi-professional use.
  • Easy to install using included mounting bracket, screws and fasteners.
  • Smart electronics mean no unnecessary heat generation.
  • Continuous output.
  • Two minutes of extra power for short power boosts.
Specifications
General Specifications
Nominal output voltage 13.6 V
Max. output power 136W
Nominal output power 82W
Max. output current (for 2 min. intervals) 10A
Continuous output current 6A
Nominal input voltage 24V
Input voltage range 20-32V
Galvanic isolation No
Stabilised Yes
Approvals CE, E-mark
Technical Specification
DC consumption < 10 mA
Connections Fast-on
Temperature range (ambient temp.) -13 °F to 176 °F
Sound level < 30 dBA at 1 mtr
Protection degree IP53
Cooling Natural cooling
Dimensions 3.5 x 3.4 x 2.0 inch

What's in the Box:
  • DC Master 24/12-6A Non isolated
  • Mounting bracket with fastenrs
  • Documentation
