31 INCH DOCK MOUNT MARINE POWER PEDESTAL - 50/30/20/1H2O/1HH/LED&P/DIRECT

PART NUMBER: SPC-36-3A-BG1

DESCRIPTION:

The 36” pedestal SPC-36-3A is designed to be mounted vertically on the dock. The SPC-36-3A comes with 3 outlets. (1) 50 AMP, (1) 30 AMP and (1) 20 AMP mounted at a 45 degree down angle with aluminum powder coated covers to match the pedestal plus (1) Hose Holder, (1) faucet and LED light with photocell.

EQUIPPED WITH:

(1) 50 AMP 125/250V twistlock receptacles

(1) 30 AMP 125V twistlock receptacles

(1) 20 AMP GFCI duplex receptacles

(1) Hose Holder

(1) Water faucet

(1) LED light and photocell

FEATURES:

All aluminum construction that has a powder-coated white finish inside and out

      (no plastic/fiberglass)

All hardware is stainless steel

Each receptacle is protected by an individual circuit breaker

All receptacles are mounted at a 45 degree down angle and are back-lit for ease of use

Custom configurations and colors also available, call for quote.

NOTE: All our standard Pedestals are equipped with SQ D Non-GFI breakers.

If you require GFI (5Ma) or EPD (30Ma) breakers please contact our Sales Team

so they can assist you.

DIMENSIONS:  6” X 6“ X 36” tall

Box Dimensions 12x12x46

Weight 35lbs
